5052 marine grade aluminum plate sheet

5052 marine grade aluminum plate sheet contains nominally contains 2.5% magnesium & 0.25% chromium. It has good workability, medium static strength, high fatigue strength, good weldability, and very good corrosion resistance, especially in marine atmospheres. It also has the low density and excellent thermal conductivity common to all aluminium alloys.

The exceptional corrosion resistance of 5052 marine grade aluminum plate sheet alloy against seawater and salt spray makes it a primary candidate for the failure-sensitive large marine structures, like tanks of Liquefied natural gas tankers, typical applications include marine, aircraft, heat exchangers, fuel lines and tanks, flooring panels etc.

Alloy Grade: 5052
Temper: O, H111. H112, H24, H32,H34,H36
Dimensions: T(1.5-120) X W(1000-3100) X (1000-13000)mm
Certificate: BV /DNV /ABS/Lioyds
Applications: Aluminum is the material of first selection of designers in high-speed ship, such as express ferries, LNG spherical tank type fluid reservoirs, hydrofoils, offshore working ships and yachts, and is widely used to shipboards, bottom plating, portholes, carrier plates and side plates of ship containers, etc.
Product Features: Long width, anti-corrosion, small elastic modulus, easy to welding, easy processing, without low temperature brittleness as well as non-magnetic.

5052 marine grade aluminum plate sheet composition
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Ga	Others		Alu
											Each	Toal
5052	0.25	0.40	0.1	0.1	2.2-2.8	0.15--0.35	-	0.10	-	-	0.05	0.15	Remainder

5052 Marine Grade Aluminum Specification & Performance
Temper	Specified thickness(mm)		Rm MPa		Rp0,2 MPa		Elongation min. %		Bend radiusa		Hardness HBWa
Temper	over	up to	min.	max.	min.	max.	A50 mm	A	180°	9o°
Fa	≥2,5	80,0	165
O/H111	0,2	0,5	170	215	65		12		0t	0t	47
	0.5	1.5	170	215	65		14		0t	0t	47
	1.5	3.0	170	215	65		16		0.5t	0.5t	47
	3.0	6.0	170	215	65		18			1.0t	47
	6.0	12.5	165	215	65		19			2.0t	46
	12.5	80.0	165	215	65		12				46
H112	≥6.0	12.5	190		80		7				55
	12.5	40.0	170		70			10			47
	40.0	80.0	170		70			14			47
H12	0.2	0.5	210	260	160		4				63
	0.5	1.5	210	260	160		5				63
	1.5	3.0	210	260	160		6				63
	3.0	6.0	210	260	160		8				63
	6.0	12.5	210	260	160		10				63
	12.5	40.0	210	260	160			9			63
H14	0.2	0.5	230	280	180		3				69
	0.5	1.5	230	280	180		3				69
	1.5	3.0	230	280	180		4				69
	3.0	6.0	230	280	180		4				69
	6.0	12.5	230	280	180		5				69
	12.5	25.0	230	280	180			4			69
H16	0.2	0.5	250	300	210		2				76
	0.5	1.5	250	300	210		3				76
	1.5	3.0	250	300	210		3				76
	3.0	6.0	250	300	210		3				76
H18	0.2	0.5	270		240		1				83
	0.5	1.5	270		240		2				83
	1.5	3.0	270		240		2				83
H22/H32	0.2	0.5	210	260	130		5		1.5t	0.5t	61
	0.5	1.5	210	260	130		6		1.5t	1.0t	61
	1.5	3.0	210	260	130		7		1.5t	1.5t	61
	3.0	6.0	210	260	130		10			1.5t	61
	6.0	12.5	210	260	130		12				61
	12.5	40.0	210	260	130			12			61
H24/H34	0.2	0.5	230	280	150		4		2.0t	0.5t	67
	0.5	1.5	230	280	150		5		2.0t	1.5t	67
	1.5	3.0	230	280	150		6		2.0t	2.0t	67
	3.0	6.0	230	280	150		7			2.5t	67
	6.0	12.5	230	280	150		9			3.0t	67
	12.5	25.0	230	280	150			9			67
H26/H36	0.2	0.5	250	300	180		3			1.5t	74
	0.5	1.5	250	300	180		4			2.0t	74
	1.5	3.0	250	300	180		5			3.0t	74
	3.0	6.0	250	300	180		6			3.5t	74
H28/H38	0.2	0.5	270		210		3				81
	0.5	1.5	270		210		3				81
	1.5	3.0	270		210		4				81
For information only
